Description
- Extremely light and compact cordless hammer with integrated extraction interface
- Maximum drill performance, efficiency and service life thanks to brushless technology and high-performance hammer action
- Dust-free drilling with compact dust extraction ISA 24 (accessory)
- Combination hammer with 3 functions: hammer drilling, drilling and chiselling
- Metabo VibraTech (MVT): integrated damping system to reduce vibrations in order to protect the user’s health
- Metabo Quick: quick change between SDS Plus hammer chuck and keyless chuck for many different applications
- Vario-Tacho-Constamatic (VTC)-Full Wave Electronics for work with materials requiring customised speeds, which remain constant under load
- Electronic soft start for precise spot-drilling
- Double safety when the drill bit jams: No kick-back thanks to the mechanic decoupling plus ultra-fast sensor-controlled shutdown
- LED work light for optimum view of the drilling site
- Many brands, one battery pack system: This product can be combined with all 18V battery packs and chargers of the CAS brands: www.cordless-alliance-systems.com
The machine shown may differ in equipment and technical details depending on the configuration.
Kindly pay attention to delivery scope and product description.
Accessories included only if listed in the delivery scope.
Kindly pay attention to delivery scope and product description.
Accessories included only if listed in the delivery scope.
Battery voltage: 18 V
Max. single blow energy (EPTA): 2.2 J
Maximum impact rate: 4750 bpm
Drill-Ø concrete with hammer drills: 24 mm
Tool holder: SDS-max
Technical Data:
Characteristics
Battery voltage 18 V
Max. single blow energy (EPTA) 2.2 J
Maximum impact rate 4750 bpm
Drill-Ø concrete with hammer drills 24 mm
Drill-Ø masonry with core bits 82 mm
Drill Ø steel 13 mm
Drill-Ø soft wood 30 mm
No-load speed 0 – 1280 rpm
Tool holder SDS-plus
Weight without battery pack 3 kg
Vibration
Hammer drilling concrete 13.4 m/s²
Uncertainty of measurement K 1.5 m/s²
Chiseling 9.1 m/s²
Uncertainty of measurement K 1.5 m/s²
Noise emission
Sound pressure level 90 dB(A)
Sound power level (LwA) 101 dB(A)
Uncertainty of measurement K 3 dB(A)
