Description
- Reliable, powerful hammer drill for all standard drilling and screwdriving applications
- Hammer drill function for drilling in masonry
- Integrated LED work light with afterglow function for optimal brightness in the work area
- With handy belt hook and bit case which can be fixed either on the right or left side
- With metaBOX, the intelligent solution for transport and storage
- Many brands, one battery pack system: This product can be combined with all 18V battery packs and chargers of the CAS brands: www.cordless-alliance-systems.com
The machine shown may differ in equipment and technical details depending on the configuration.
Kindly pay attention to delivery scope and product description.
Accessories included only if listed in the delivery scope.
Kindly pay attention to delivery scope and product description.
Accessories included only if listed in the delivery scope.
Battery voltage:18 V
Maximum torque, soft: 25 Nm
Maximum torque, hard: 50 Nm
Drill-Ø masonry: 10 mm
Drill Ø steel: 10 mm
Drill-Ø soft wood: 20 mm
No-load speed: 450 / 1800 rpm
Maximum torque, soft: 25 Nm
Maximum torque, hard: 50 Nm
Drill-Ø masonry: 10 mm
Drill Ø steel: 10 mm
Drill-Ø soft wood: 20 mm
No-load speed: 450 / 1800 rpm
Technical Data:
Characteristics
Type of battery pack LiPOWER
Battery voltage 18 V
Battery pack capacity 2 x 2 Ah
Maximum torque, soft 25 Nm
Maximum torque, hard 50 Nm
Adjustable torque 1.5 – 6 Nm
Drill-Ø masonry 10 mm
Drill Ø steel 10 mm
Drill-Ø soft wood 20 mm
No-load speed 450 / 1800 rpm
Maximum impact rate 27000 bpm
Chuck capacity 1.5 – 13 mm
Weight without battery pack 1.2 kg
Weight with battery pack 1.7 kg
Vibration
Drilling in metal 2.8 m/s²
Uncertainty of measurement K 1.5 m/s²
Impact drilling concrete 21.5 m/s²
Uncertainty of measurement K 1.5 m/s²
Noise emission
Sound pressure level 89 dB(A)
Sound power level (LwA) 100 dB(A)
Uncertainty of measurement K 3 dB(A)
