Description
- A powerful all-around choice: easy to handle hammer drill with brushless power for challenging drilling and screw fitting applications
- Powerful Brushless motor for greatest efficiency and long battery pack runtime
- High-performance impact mechanism for optimum drilling performance
- Overload protection: protects the motor from overheating
- Integrated working light to illuminate the contact area
- Integrated LED work light with afterglow function for optimal brightness in the work area
- With handy belt hook and bit case which can be fixed either on the right or left side
- LiHD battery pack for ultimate performance, extremely long runtime and service life
- With metaBOX, the intelligent solution for transport and storage
- Many brands, one battery pack system: This product can be combined with all 18V battery packs and chargers of the CAS brands: www.cordless-alliance-systems.com
The machine shown may differ in equipment and technical details depending on the configuration.
Kindly pay attention to delivery scope and product description.
Accessories included only if listed in the delivery scope.
Kindly pay attention to delivery scope and product description.
Accessories included only if listed in the delivery scope.
Battery voltage:18 V
Maximum torque, soft: 34 Nm
Maximum torque, hard: 75 Nm
Drill-Ø masonry: 13 mm
Drill Ø steel: 13 mm
Drill-Ø soft wood: 38 mm
No-load speed: 0 – 600 / 0 – 2100 rpm
Maximum torque, soft: 34 Nm
Maximum torque, hard: 75 Nm
Drill-Ø masonry: 13 mm
Drill Ø steel: 13 mm
Drill-Ø soft wood: 38 mm
No-load speed: 0 – 600 / 0 – 2100 rpm
Technical Data:
Characteristics
Type of battery pack LiHD
Battery voltage 18 V
Battery pack capacity 2 x 4 Ah
Maximum torque, soft 34 Nm
Maximum torque, hard 75 Nm
Adjustable torque 0.7 – 8 Nm
Drill-Ø masonry 13 mm
Drill Ø steel 13 mm
Drill-Ø soft wood 38 mm
No-load speed 0 – 600 / 0 – 2100 rpm
Maximum impact rate 31950 bpm
Chuck capacity 1.5 – 13 mm
Weight without battery pack 1.2 kg
Weight with battery pack 1.8 kg
Vibration
Drilling in metal 2.9 m/s²
Uncertainty of measurement K 1.5 m/s²
Impact drilling concrete 17.3 m/s²
Uncertainty of measurement K 1.5 m/s²
Noise emission
Sound pressure level 91 dB(A)
Sound power level (LwA) 102 dB(A)
Uncertainty of measurement K 3 dB(A)
